High Pressure (0-40 Bar) Series
High Pressure (0-40 Bar) Reciprocating Air Compressor
Exactly What You Expect At High Pressure…
Since 1978, Yigitsan has been manufacturing Reciprocating Air Compressor , specializing in this field and designs two-stage and High Pressure Reciprocating Air Compressor with a structure that will ensure your work safety and with a high efficiency working capacity. A plenty of spare parts, widespread service network and 2-year factory warranty will fully meet your expectations for high pressure High Pressure Reciprocating Air Compressor .Our High Pressure Reciprocating Air Compressor product range extends from 0-40 bar pressure, 570 lt/min piston displacement to 2.015 lt/min.
High Pressure (0-40 Bar) Series in Numbers
Motor
4 – 18,5 kW
Air Efficiency
570 – 2.015 l/dk
Working Pressure
40 bar
Superior Features of High Pressure (0-40 Bar) Series
- %100 Domestic
- Cast Body
- High Efficiency
- Independent cooling fan
- Aluminum air cooling system
- Long-Lasting
- Widespread service network
- Plenty of spare parts
- Optional 400 V – 60 Hz
- Optional control panel
Capacity Table
| Model | Air Efficiency | Working Pressure | Motor Power | |
|---|---|---|---|---|
| L/min. | CFM | kW | HP | |
| Y-2110-1 KŞ | 570 | 40 | 4 | 5,5 |
| Y-390-2 KŞ | 760 | 40 | 5,5 | 7,5 |
| Y-3110-2 KŞ | 1000 | 40 | 11 | 15 |
| Y-3110-2H KŞ | 1700 | 40 | 15 | 20 |
| Y-3160-2 KŞ | 2015 | 40 | 18,5 | 25 |
All capacities are measured according to ISO 1217 standards at 1 BAR pressure and 20°C ambient temperature.
Sound levels are measured in accordance with Pneurop standards.
For detailed brochures, product availability, or consultancy services, please feel free to contact us.
We reserve the right to modify technical specifications without prior notice.
