Silobas Series
Low Pressure Reciprocating Air Compressors
Also Low Pressure At Yigitsan!
Yigitsan Compressor has offered its Low Pressure Reciprocating Air Compressors designed for use in pneumatic transportation operations to introduce new technologies and to meet the specific needs of your company. Our Low Pressure Reciprocating Air Compressors, which are offered in three different capacities for electric motors, can also be coupled with diesel engines and serve in regions where energy is limited or absent.
Silobas Series in Numbers
Motor
15 – 22 kW
Piston Displacement
4.800-10.500 l/dk
Working Pressure
3,5 bar
Superior Features of Silobas Series
- Simple and balanced constructions
- Direct coupled system
- 3.5 bar outlet pressure
- Safety valve
- Aluminum piston
- Air outlet pressure manometer
- Oil level indicator
- Protective housing
- Balanced and ground crank
- Intake valve system that minimizes dead volume
- Needle roller bearing system that minimizes mechanical friction
- High efficiency cooling diagnosis
- Local manufacturing, plenty of spare parts
- Widespread technical service network
Capacity Table
| Model | Piston Displacement | Working Pressure | Motor Power | |
|---|---|---|---|---|
| l/min. | bar | kW | HP | |
| Y-2160 KŞ | 4800 | 3,5 | 15 | 20 |
| Y-3160 KŞ | 7200 | 3,5 | 18,5 | 25 |
| Y-2220 KŞ | 10500 | 3,5 | 22 | 30 |
All capacities are measured according to ISO 1217 standards at 1 BAR pressure and 20°C ambient temperature.
Sound levels are measured in accordance with Pneurop standards.
For detailed brochures, product availability, or consultancy services, please feel free to contact us.
We reserve the right to modify technical specifications without prior notice.
Gallery
