YSD Series

Mobile Diesel Rotary Screw Air Compressors

Wherever You Go, Your Air Goes There…

Our Mobile Diesel Rotary Screw Air Compressors are the most suitable solution for sectors with large areas and unstable sectors such as construction, mining and drilling. Our Mobile Diesel Rotary Screw Air Compressors with the desired flow rate and pressure are always with you, with their safe work safety, high efficiency working capacity, plenty of spare parts and widespread service network. With a casing design that allows easy access to every point and provides easy maintenance, The Mobile Diesel Rotary Screw Air Compressors that we have produced with free air efficiency ranging from 2.2 m³/min to 30.07 m³/min can also meet compressed air needs at different pressures and flow rates if desired. You ask, we do it!

  • Specially manufactured fuel tank to be resistant to corrosion
  • Pneumatic control system manufactured by YIGITSAN that adjusts the engine speed depending on the amount of air needed, increasing fuel economy and efficiency.
  • Pressurized lubrication circuit providing efficient lubrication
  • Separator tank
  • Air/oil separator that ensures optimum separation of air from oil
  • Air filter that provides more efficient filtration of the air drawn by the screw group
  • Two-stage air filter for motor partition
  • Cooling system that ensures efficient operation of the unit even at extremely high ambient temperatures
  • Integrated radiator that cools the oil of the compressor
  • Modern designed, painted with advanced technology painting techniques, providing durability (electrostatic powder paint) long-lived case
  • Top case that facilitates periodic maintenance and provides easy access to interior of the machine
  • Non-deformable, durable special mudguards

YSD Series in Numbers

Motor

23 – 265 kW

Air Efficiency

2,2 – 30,7 m³/dk

Working Pressure

7 – 10 – 13 bar

Superior Features of YSD Series

  • Long-lasting
  • It has a design suitable for long-term efficient operation.
  • It is offered with the privilege of domestic production and plenty of spare parts.
  • Easy maneuverability and fast transportation even in the most difficult conditions with its compact structure and special design.
  • Environmentally friendly (there are special designs for exhaust suction direction and noise guidelines)
  • Easy maintenance advantage with professional cabin design
  • Optional trailer – option without trailer
  • Easy-to-use control panel

Capacity Table

Model Air Efficiency Working Pressure Motor Power
m³/min. bar 7 Bar
(kW)		 10 Bar
(kW)		 13 Bar
(kW)
YSD 1220 2,2 7/10/13 23 26 29
YSD 1270 2,7 7/10/13 26 29 32
YSD 3200 3,2 7/10/13 29 32 40
YSD 3700 3,7 7/10/13 32 40 44
YSD 4500 4,5 7/10/13 40 44 48
YSD 5100 5,1 7/10/13 44 48 50
YSD 6400 6,4 7/10/13 48 50 54
YSD 7200 7,2 7/10/13 50 54 62
YSD 8100 8,1 7/10/13 54 62 82
YSD 9200 9,2 7/10/13 62 82 90
YSD 11100 11,1 7/10/13 82 90 92
YSD 13000 13 7/10/13 90 92 102
YSD 15200 15,2 7/10/13 92 102 114
YSD 17200 17,2 7/10/13 102 114 120
YSD 19300 19,3 7/10/13 114 120 130
YSD 20500 20,5 7/10/13 120 130 150
YSD 22100 22,1 7/10/13 130 150 180
YSD 24400 24,4 7/10/13 150 180 200
YSD 27500 27,5 7/10/13 180 200 220
YSD 30700 30,7 7/10/13 200 220 265

All capacities are measured according to ISO 1217 standards at 1 BAR pressure and 20°C ambient temperature.
Sound levels are measured in accordance with Pneurop standards.
For detailed brochures, product availability, or consultancy services, please feel free to contact us.
We reserve the right to modify technical specifications without prior notice.
