YVK D Series
Direct Coupled Rotary Screw Air Compressors
Grow Your Business, Grow Your Success!
Yigitsan YVK D Series reduces power transmission losses and provides energy cost advantages thanks to its direct-drive screw motor system. These Air Compressors work perfectly in the most difficult conditions and have a long service life with maximum operating time. The YVK D Series offers exceptional value for all businesses energy efficiency, easy maintenance, and remote monitoring capabilities. When you need a reliable compressor that does not put pressure on the budget, YVK D Series will be your ideal choice.
YVK D Series in Numbers
Motor
15 – 500 kW
Air Efficiency
1,8 – 71,2 m³/dk
Working Pressure
8-10-13 bar
Superior Features of YVK D Series
- High efficiency,
- Minimizing power transmission losses thanks to the coupled system
- Support for operating costs thanks to long maintenance terms
- Start/stop at specified working hours with remote monitoring system
- Superior performance even under the most difficult conditions
- Easy to find spare parts and warranty
Capacity Table
| Model | Air Efficiency | Motor Power | |||
|---|---|---|---|---|---|
| 8 bar m³/min. |
10 bar m³/min. |
13 bar m³/min. |
kW | HP | |
| YVK 20 D | 2,7 | 2,2 | 1,8 | 15 | 20 |
| YVK 25 D | 3,2 | 2,7 | 2,2 | 18,5 | 25 |
| YVK 30 D | 4 | 3,2 | 2,8 | 22 | 30 |
| YVK 40 D | 5,4 | 4,7 | 3,8 | 30 | 40 |
| YVK 50 D | 6,5 | 5,4 | 4,5 | 37 | 50 |
| YVK 60 D | 8,5 | 7,3 | 6,1 | 45 | 60 |
| YVK 75 D | 10 | 8,6 | 7,3 | 55 | 75 |
| YVK 100 D | 13,9 | 11,8 | 9,9 | 75 | 100 |
| YVK 120 D | 16,1 | 13,3 | 11,4 | 90 | 125 |
| YVK 150 D | 19,4 | 16,2 | 14,2 | 110 | 150 |
| YVK 180 D | 25,8 | 21,5 | 17,8 | 132 | 180 |
| YVK 220 D | 28,5 | 25,1 | 21,3 | 160 | 220 |
| YVK 270 D | 36,9 | 31,2 | 25,7 | 200 | 270 |
| YVK 340 D | 45 | 40,1 | 33 | 250 | 340 |
| YVK 430 D | 55 | 46,5 | 41,3 | 3150 | 430 |
| YVK 540 D | 65 | 57,6 | – | 400 | 540 |
| YVK 680 D | 71,2 | – | – | 500 | 680 |
All capacities are measured according to ISO 1217 standards at 1 BAR pressure and 20°C ambient temperature.
Sound levels are measured in accordance with Pneurop standards.
For detailed brochures, product availability, or consultancy services, please feel free to contact us.
We reserve the right to modify technical specifications without prior notice.
