YVK Series
Belt Driven Rotary Screw Air Compressors
Grow Your Business, Grow Your Success!
Yigitsan YVK Series is unique with its durability for long-term performance. These air compressors provide excellent performance in the most difficult conditions, ensuring maximum uptime and long life. The YVK Series sets the standard for excellence in compressed air maintenance and offers exceptional value to any business. When you need a reliable compressor that does not put pressure on the budget, YVK Series will be your ideal choice.
YVK Series in Numbers
Motor
2,2 – 250 kW
Air Efficiency
0,17 – 44 m³/dk
Working Pressure
8-10-13 bar
Superior Features of YVK Series
- High efficiency,
- Support for operating costs thanks to long maintenance terms
- Start/stop at specified working hours with remote monitoring system
- Superior performance even under the most difficult conditions
- Easy to find spare parts and warranty
Capacity Table
| Model | Air Efficiency | Motor Power | |||
|---|---|---|---|---|---|
| 8 bar m³/min. |
10 bar m³/min. |
13 bar m³/min. |
kW | HP | |
| YVK 3 | 0,37 | 0,25 | 0,17 | 2,2 | 3 |
| YVK 4 | 0,45 | 0,37 | 0,26 | 3 | 4 |
| YVK 5 | 0,54 | 0,41 | 0,32 | 4 | 5 |
| YVK 7 | 0,86 | 0,69 | 0,45 | 5,5 | 7,5 |
| YVK 10 | 1,2 | 0,9 | 0,7 | 7,5 | 10 |
| YVK 15 | 1,8 | 1,4 | 1,1 | 11 | 15 |
| YVK 20 | 2,6 | 2,1 | 1,7 | 15 | 20 |
| YVK 25 | 3,1 | 2,6 | 2,1 | 18,5 | 25 |
| YVK 30 | 3,8 | 3 | 2,6 | 22 | 30 |
| YVK 40 | 5,2 | 4,5 | 3,6 | 30 | 40 |
| YVK 50 | 6,3 | 5,2 | 4,3 | 37 | 50 |
| YVK 60 | 7,2 | 6,2 | 5,3 | 45 | 60 |
| YVK 75 | 9,8 | 8,2 | 7 | 55 | 75 |
| YVK 100 | 12,6 | 11,3 | 9,5 | 75 | 100 |
| YVK 120 | 15,1 | 13 | 11 | 90 | 125 |
| YVK 150 | 19,1 | 15,8 | 13,9 | 110 | 150 |
| YVK 180 | 23,1 | 20,8 | 17,3 | 132 | 180 |
| YVK 220 | 28 | 24,8 | 20,9 | 160 | 220 |
| YVK 270 | 35,5 | 30,8 | 25,3 | 200 | 270 |
| YVK 340 | 44 | 39,1 | 32,4 | 250 | 340 |
All capacities are measured according to ISO 1217 standards at 1 BAR pressure and 20°C ambient temperature.
Sound levels are measured in accordance with Pneurop standards.
For detailed brochures, product availability, or consultancy services, please feel free to contact us.
We reserve the right to modify technical specifications without prior notice.
