Breathing Air Compressor Series (0-330 Bar)

Breathing Air Compressor Series (0-330 Bar)

Smel of Nature…

You can use portable or stationary Yiğitsan High Pressure Breathing Air Compressor in Paintball games from lowest up to highest levels. Such as Fire Brigades, Diving Centers, Plastic manufacturing processes and Ground Service Centers in Airports you can use these compressors in wide range of areas…

Model SERBEST HAVA VERİMİ ÇALIŞMA BASINCI KADEME MOTOR GÜCÜ KOMPRESÖR DEVRİ FİLTRE
L/dk. (mn) Cfm BAR PSI Kw HP
BM ŞASE MANTAJI
YYB 100 BM 100 3,5 230 3300 3 2,2 3 780 YP21
YYB 100 BM 100 3,5 330 4785 3 2,2 3 820 YP21
YYB 150 BM 150 5,2 230 3330 3 3 4 800 YP21
YYB 150 BM 150 5,2 330 4785 3 3 4 860 YP21
YYB 210 BM 210 7,5 230 3330 3 4 5,5 680 YP21
YYB 210 BM 210 7,5 330 4785 3 4 5,5 740 YP21
YYB 270 BM 270 9,5 230 3330 3 5,5 7,5 750 YP21
YYB 100 P 100 3,5 330 4785 3 4 5,5 820 YP21
YYB 150 P 150 5,2 230 3330 3 4,5 6 800 YP21
YYB 150 P 150 5,2 330 4785 3 4,5 6 860 YP21
YYB 210 P 210 7,5 230 3330 3 5,5 7,5 680 YP21
YYB 210 P 210 7,5 330 4785 3 5,5 7,5 740 YP21
YYB 270 P 270 9,5 230 330 3 6,5 9 750 YP21
YYB 270 P 270 9,5 330 4785 3 6,5 9 800 YP21
YYB 330 P 330 11,5 230 3330 3 9,5 13 710 YP41
YYB 330 P 330 11,5 330 4785 3 9,5 13 790 YP41
C KABİNLİ
YYB 210 C 210 5,2 230 3300 3 4 5,5 680 YP41
YYB 270 C 270 9,5 330 4785 3 5,5 7,5 750 YP41
YYB 330 C 330 11,5 230 3330 3 7,5 10 710 YP41
YYB 330 C 330 11,5 330 4785 3 7,5 10 790 YP41
YYB 450 C 510 18 230 3330 3 11 15 770 YP41
YYB 450 C 510 18 330 4785 3 11 15 840 YP41
YYB 680 C 680 24 230 330 3 15 20 720 YP61
YYB 680 C 680 24 330 4785 3 15 20 810 YP61
KISALTMALAR
YYB YİĞİTSAN BASINÇ SOLUNUM HAVASI KOMPRESÖRÜ
BM ŞASE MANTAJI
P BENZİNLİ
C KABİNLİ
YP YİĞİTSAN FİLTRE

Our Breathing Air Type High Pressure compressors are entirely our own production and have a cast body.
According to their capacity;
Our designs are divided into two: on-chassis design and models mounted inside the cabin.
In addition to the electric motor, our gasoline engine types are offered optionally.

Stainless Purifier Filter and replaceable internal element
High pressure particle inhibitor -0.001 ppm oil inhibitor active carbon filter (stainless)
Cooling system with stainless pipes (All Intermediate and After Coolers)
Interstage dehumidifier
automatic drain
Oil level sensor (Optional)
Safety valve and manometer between each stage
YΔ Electrical Panel
Axial Fan Cooling (For cabin models)
Anti-vibration mount



Start – Stop Buttons
Manometer between each stage
Emergency Stop Button
Status and Fault notification warning lamps
Main Engine Thermal Malfunction
Working hours counter
Filling Panel (Optional)
Oil Level Notification Lamp (Optional)
Pressure Selection Switch (Optional)

Our products are produced in accordance with EN 12021 Breathing Air Standards.
